Process Control & Industrial Automation Solution — GE Fanuc IC670ALG330 | Series 90-70
Where This Product Is Used
The GE Fanuc IC670ALG330 is a 4-channel analog output module engineered for the GE Series 90-70 PLC platform. It is deployed across demanding industrial environments where precise analog signal control is critical:
- Chemical & Petrochemical Plants — Modulating control valves, flow regulators, and pressure transmitters via 4–20 mA loops
- Water & Wastewater Treatment — Pump speed control and dosing system regulation through variable voltage/current outputs
- Automotive Manufacturing — Servo drive reference signals and conveyor tension control in body-shop and paint-line automation
- Power Generation & Utilities — Turbine governor setpoint control and excitation system interface
- Food & Beverage Processing — Temperature zone setpoint delivery to PID controllers and variable-frequency drives (VFDs)
- Pulp & Paper Mills — Web tension and dryer section speed reference outputs
- HVAC & Building Automation — Chiller and AHU control via 0–10 V analog command signals
Technical Specifications
| Part Number | IC670ALG330 |
| Series | GE Series 90-70 (Genius I/O) |
| Module Type | Analog Output |
| Number of Channels | 4 Channels |
| Output Signal Range | 4–20 mA / 0–10 V DC (configurable per channel) |
| Resolution | 12-bit (1 in 4,096) |
| Output Isolation | Channel-to-channel and channel-to-bus isolation |
| Power Consumption | Supplied via Series 90-70 backplane |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | 450 g |
| Form Factor | Single-slot Series 90-70 rack module |
| Manufacturer | GE Fanuc Automation |
Why Engineers Specify This Model
- Dual-mode output flexibility — Each channel independently configurable for current (4–20 mA) or voltage (0–10 V) without hardware changes
- 12-bit resolution — Delivers 0.024% full-scale accuracy, meeting the precision demands of PID loop control and servo reference applications
- Native Series 90-70 integration — Plug-and-play compatibility with GE 90-70 racks; no external signal conditioners required
- Channel isolation — Prevents ground loops in multi-instrument installations, reducing noise-induced setpoint drift
- Proven field reliability — Widely deployed in continuous-process industries since the 1990s; extensive installed base ensures long-term spare availability
- Configurable via Logicmaster / Proficy ME — Seamless integration with GE programming environments; no custom driver development needed
Complete System Bill of Materials
For a fully operational Series 90-70 analog output subsystem, engineers typically specify:
- IC670ALG330 — This analog output module (4-ch, 12-bit)
- IC697CHS750 / IC697CHS782 — Series 90-70 rack (5-slot or 9-slot)
- IC697PWR710 / IC697PWR711 — Series 90-70 power supply module
- IC697CPU772 / IC697CPU781 — Series 90-70 CPU module
- IC697BEM711 — Genius Bus Controller (if using Genius I/O network)
- IC670CBL001 — Field wiring terminal block / cable assembly
Contact support@konmask.com for bundle pricing on complete rack assemblies.
Compliance & Industry Standards
- Designed and manufactured to IEC 61131-2 programmable controller hardware requirements
- Compatible with NAMUR NE 43 signal range conventions (4–20 mA)
- Suitable for installations requiring CE marking compliance (verify with your system integrator for specific directives)
- RoHS status: Legacy product — consult datasheet for material declaration
Quality Assurance & Sourcing
- Tested before shipment — Each unit undergoes functional power-on verification and output channel calibration check
- Genuine OEM hardware — Sourced from authorized distributors and decommissioned OEM systems; no counterfeit or refurbished-as-new misrepresentation
- Inspection report available — Request a pre-shipment inspection certificate with your order
- Packaging — Anti-static bag + foam-lined carton; meets JEDEC JESD22-A114 ESD handling standards
- Warranty — 90-day functional warranty; DOA replacement within 7 business days
How to Source This Part
- Add to cart and complete checkout at Konmask.com
- For bulk orders (5+ units), RFQ, or lead-time confirmation — email support@konmask.com
- Expedited shipping available via DHL Express, FedEx IP, and UPS Worldwide
- Export documentation (commercial invoice, packing list, COO) provided for international orders
- Payment: T/T bank transfer, PayPal, credit card via Shopify Payments
Application-Specific FAQ
Q: Is the IC670ALG330 compatible with the IC697 rack series?
A: Yes. The IC670ALG330 is a Genius I/O module that mounts in IC697-series racks via the Series 90-70 backplane. Confirm slot compatibility with your rack model before ordering.
Q: Can I use this module for 0–20 mA output instead of 4–20 mA?
A: The module is factory-configured for 4–20 mA. Some firmware versions support 0–20 mA via software configuration in Logicmaster 90 or Proficy Machine Edition — consult GE datasheet GFK-0898 for your specific firmware revision.
Q: What is the maximum loop impedance for the current output channels?
A: The 4–20 mA current output supports a maximum load impedance of 750 Ω at 24 VDC supply. Verify your field device input impedance before wiring.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. A CoC and functional test report can be included with shipment upon request. Contact us before placing your order to arrange documentation.
Q: Can this module replace an IC670ALG320?
A: The IC670ALG320 is a 2-channel analog output module; the IC670ALG330 provides 4 channels. They share the same form factor and backplane interface. Verify your application’s channel count and software configuration before substituting.
